Description

PS-D1201 DC12V 1000mA Power Supply AC100/240V UL Listed

Features

* Operational Input Voltage 100V To 240V AC
* High Efficiency
* Short Circuit Protection surge protection Overload Protection
* Ripple=50Mv

Specification

Rated Input Voltage: 100V To 240V AC
Rated Input Current: 350mA RMS Maximum
Output Voltage: 12V DC
Output Current: 1A
Frequency Rated: 50-60 Hz
Efficiency: 82% Minimum
Leakage Current: 0.65mA
Over Voltage Protection: 15
Short Circuit Protection: Output is Shut Down & Automatic Restart
Load Regulation: A± 5%
Safety Approval: CE, UL,CUL, GS
EMI Standard (optional): Meets FCC Class B /CE / VCCI-11
Dimensions (W x H x D): 70 x 65 x 24 mm
Operating Conditions: Temperature: 0°C ~ +40°C, Humidity: 20% ~ 80%
