Description

LC/UPC-LC/UPC 10Gb 50/125 OM3 Multimode Duplex Fiber Optic Cable Aqua.

This LC/UPC-LC/UPC 10Gb 50/125 OM3 multimode duplex fiber optic cable delivers reliable high-speed data transmission up to 10Gbps. Designed with OM3 aqua-rated multimode fiber, it supports enhanced bandwidth and extended reach, ideal for modern data centers and enterprise networks. Its duplex LC/UPC connectors ensure precise, low-loss connections for optimal performance. Engineered for durability and efficient signal integrity, this cable is perfect for scalable network infrastructures requiring robust and efficient fiber connectivity.

* Our high-quality OM3 multi-mode fiber cable with LC/LC connectors is perfect for high-throughput applications.
* Support 10Gb up to 300 meters, 40Gb, and 100Gb up to 100 meters.
* With an Effective Modal Bandwidth (EMB) of 2000 MHz/km at 850nm.
* LSZH/OFNR (riser) rated fiber cable is ideal for use in upright shafts that run between floors in the building.
* The small LC connector is perfect for high-density network applications.
* Use with LED and VCSEL laser light sources.
* Backward compatible with LED-based 50/125 multimode fiber applications.
* Corning® glass 50μm core and 125μm cladding.
* Test report included in each cable package.
* UL Listed

Connector Type: LC-LC Multimode
Polishing: UPC to UPC
Return Loss: ≥ 55 dB
Insertion Loss: ≤ 0.30 dB
Cabled Optical Fiber: OM3
Nominal Diameter Core: 50/125 µm
Jacket Material: OFNR/LSZH
Jacket Color: Aqua
