Description

LC/UPC-LC/UPC 62.5/125 OM1 Multimode Duplex Fiber Optic Cable.

The LC/UPC-LC/UPC OM1 Multimode Duplex 62.5/125 Fiber Optic Patch Cable is engineered for reliable high-speed data transmission in multimode optical networks. Featuring precision LC/UPC connectors on both ends, it ensures low insertion loss and high return loss for optimal signal quality. The 62.5/125 µm core/cladding diameter supports legacy OM1 systems, making it ideal for short-distance applications such as LANs and data centers. Its duplex design facilitates simultaneous bidirectional communication, enhancing network efficiency and flexibility.

* Our high-quality OM1 62.5/125 multimode fiber cable with LC/LC connectors is perfect for fast Ethernet, fiber channel, gigabit Ethernet, data center, ATM, and other data applications.
* OFNR (riser) rated fiber cable is ideal for use in upright shafts that run between floors in the building.
* The small LC connector is perfect for high-density network applications.
* Use with the LED light source.
* Corning® glass 62.5μm core and 125μm cladding.
* Test report included in each cable package.

Connector Type: LC-LC Multimode
Polishing: UPC
Return Loss: ≥ 55dB
Insertion Loss: ≤ 0.30dB
Ferrule Material: Ceramic (zirconia)
Ferrule Diameter: 1.25 mm / 2.5 mm
Cabled Optical Fiber: OM1
Nominal Diameter Core: 62.5/125 µm
Jacket Material: OFNR/LSZH
Operation Temperature Range: -20°C +70°C
